Aren’t you a scientist? No worries!
With our “DROPLET GENERATOR S”, anyone, anywhere can easily generate droplets.
EASY OPERATION
Various adjustment tasks previously performed via software installed on a conventional PC have been consolidated into dial operation on the main unit.
Two LCD-equipped dials for oil and sample adjustment are positioned on the top of the unit. Intuitive dial operation enables adjustment of sample and oil pressure values and operating time. This achieves a significant improvement in operability.
SPACE-SAVING
Are you fed up with laboratories crammed full of experimental equipment? The compact DG S won’t take up much space.
Weighing and measuring approximately10% of conventional models, it offers excellent portability and achieves space-saving design.
Unit Size
| Size | 200 (W) x 170 (D) x 65 (H) mm |
| Weight | 1 KG |
Product Details
| fluid delivery pressure | 0.1 – 40 kPa |
| Maximum Liquid Delivery System | Two lines (sample, oil) |
| Droplet size | Appx. 100 ㎛ |
| Power input | DC 12V |
| Power consumption | 6W |
*This product is currently under development. Please note that the product name, image and specifications are subject to change without prior notice.
Monitoring Unit
Droplet size can be monitored real-time with the supplied monitoring device.
Product Details
| Size | 215 (W) x 310 (D) x 430 (H) mm |
| Accessories | Monitor camera, Peltier unit, Controller |
| Temperature range | ー5 ～ 70℃ |
| Ambient environment | Temperature 5 – 40˚C, humidity ≤ 85% RH |
| Power input | DC24 V |
| Power consumption | 6.5 A max |
