Reagents / Chips

Sheath fluid

Ready-to-use sheath fluids are available for purchase. These contain the anti-cell adhesion reagent, Through Path Plus. Sheath fluids are used to run the cell sorter.

• Through Path Plus 40x (10mL x 6 bottles/pack)



  Catalog number	2001004-6
  Purpose of use	Coats microchannel and reservoirs of the microfluidic chip to prevent cell adhesion and thus cell loss
  Usage	Dilute 40-folds with culture medium or buffer (e.g., PBS)
  Storage condition	4℃ (use within 1 month after opening)
  Quantity	10 mL x 6 bottles/pack

• On-chip T Buffer (500 mL)



  Catalog number	2001014
  Purpose of use	Ready-to-use PBS-based buffer to suspend cells and used as sheath fluid. It contains Through Path Plus to allow coating of microchannel and reservoirs of the microfluidic chip, pipette tips and tubes to prevent cell adhesion, and thus cell loss
  Usage	Use as is ※Please open on a clean bench since the composition is similar to culture medium
  Storage condition	4℃ (use within 1 month after opening)
  Quantity	500 mL

Sample buffer

We supply buffers used to suspend cells. Those buffers contain additives to reduce the rate of cell sedimentation. They are ready-to-use, and they come in 2x solution and powder form.

• On-chip Sample Buffer 2×（50 mL)



  Catalog number	2001015
  Purpose of use	Ready-to-use serum-free cell culture medium used to suspend cells for sorting. It contains Through Path Plus to allow coating of microchannel and reservoirs of the microfluidic chip to prevent cell adhesion and thus cell loss, and viscosity agent for prolonged cell suspension
  Usage	Dilute 1:1 with sample
  Storage condition	4℃ (use within 1 month after opening)
  Quantity	50 mL
  Remarks	Dilute 1:1 with sample as the viscosity adjuster is included in the 2x concentration. Changes in viscosity will reduce sorting efficiency

FluoroSurfactant

Used for droplet production and analysis

• 008-FluoroSurfactant-5wtH-10mL



  Catalog number	2003001
  Description	Fluorinated oil containing 5% surfactant
  Quantity	10mL/bottle

  This product corresponds to “16.1g of 5 weight % 008-FluoroSurfactant in HFE7500 (cat#: 008-FluoroSurfactant-5wtH-16.14G)” provided from RAN Biotechnologies, Inc.

• 008-FluoroSurfactant-0.1wtH-100mL



  Catalog number	2003002
  Description	Fluorinated oil containing 0.1% surfactant
  Quantity	100mL/bottle

  This product corresponds to “161.4g of 0.1 weight % of 008-FluoroSurfactant in HFE7500 (cat#: 008-FluoroSurfactant-0.1wtH-161.4G)” provided from RAN Biotechnologies, Inc.

When purchasing directly from RAN Biotechnologies, visit the website, click on “FluoroSurfactants,” and select your consumables from the dropdown menu.
